Seide OSM1000 Hydraulic Hose and Cylinder Test Machine – 14,500 PSI High-Pressure Testing System

The Seide OSM1000 Hydraulic Hose and Cylinder Test Machine is designed for high-pressure testing of hydraulic hose assemblies and hydraulic cylinders. With a test pressure range of 50 to 1,000 bar (approximately 725 to 14,504 PSI), the OSM1000 provides a professional solution for hydraulic equipment manufacturers, hose assembly shops, cylinder manufacturers, and industrial service facilities.

Designed for applications requiring controlled pressure testing and leak inspection, the Seide OSM1000 supports testing with either water or hydraulic oil.

The machine features a PLC control screen, test report printing capability, USB connectivity, and a pre-filling pump to support the preparation and execution of hydraulic testing procedures.

For hydraulic hose manufacturers, OEM equipment suppliers, maintenance facilities, and industrial quality control departments, reliable pressure testing equipment is an important part of production and service operations.

Seide OSM1000 Technical Specifications

The Seide OSM1000 is designed to perform hydraulic pressure tests within a range of 50 to 1,000 bar.

Technical specifications:

  • Model: Seide OSM1000

  • Product Type: Hydraulic Hose and Cylinder Test Machine

  • Product Code: OSM1000

  • Test Pressure Range: 50–1,000 bar (approximately 725–14,504 PSI)

  • Test Media: Water and hydraulic oil

  • Control System: PLC control screen

  • Test Reporting: Printing capability

  • Data Connectivity: USB connection

  • Pre-Filling System: Integrated pre-filling pump

  • Brand: Seide

1,000 Bar Hydraulic Pressure Testing

Hydraulic hoses, hose assemblies, and hydraulic cylinders operate under different pressure conditions depending on their design and application.

Pressure testing is an important quality control procedure used to evaluate the pressure performance and leak-tightness of hydraulic equipment.

The Seide OSM1000 provides a test pressure range of 50 to 1,000 bar, making it suitable for high-pressure hydraulic testing applications.

Its maximum test pressure of 1,000 bar, equivalent to approximately 14,504 PSI, offers a wide testing range for different hydraulic components.

The appropriate test pressure must always be determined according to the component's rated pressure, manufacturer's instructions, and applicable testing procedure. The maximum machine capacity does not mean that every hose or cylinder should be tested at 1,000 bar.

Hydraulic Hose Assembly Testing

Hydraulic hoses are critical components used to transfer pressurized fluid throughout hydraulic systems.

A hydraulic hose assembly consists of the hose, reinforcement layers, end fittings, and crimped connections. Each part must be suitable for the operating pressure, temperature, fluid type, and application requirements.

Pressure testing helps evaluate the integrity and leak-tightness of completed hose assemblies after manufacturing or installation.

The Seide OSM1000 can be used for appropriate hydraulic hose testing procedures, including:

  • Post-assembly pressure testing

  • Hose and fitting leak inspections

  • High-pressure hose testing

  • Production quality control

  • Maintenance and service inspections

  • Verification of hose assembly connections

For hydraulic hose manufacturers and assembly workshops, pressure testing equipment plays an important role in maintaining consistent quality control procedures.

Hydraulic Cylinder Pressure Testing

Hydraulic cylinders convert hydraulic pressure into linear mechanical force and are widely used in construction equipment, mining machinery, agricultural machines, and industrial applications.

After manufacturing, repair, or overhaul, hydraulic cylinders may require pressure testing to evaluate their sealing performance and structural integrity under specified test conditions.

The Seide OSM1000 can be used for hydraulic cylinder testing with suitable connections and an appropriate testing procedure.

Important inspection points may include:

  • Leakage at hydraulic ports and connections

  • External leakage around sealing areas

  • Pressure retention during the specified test period

  • Cylinder body and connection integrity

  • Leakage or deformation observed during testing

The testing procedure and pressure must be selected according to the cylinder design, rated operating pressure, and manufacturer's specifications.

PLC Control System

The Seide OSM1000 features a PLC control screen for managing the machine's operating and testing processes.

The PLC-based control interface supports the operator during hydraulic pressure testing and provides a centralized control point for the equipment.

In high-pressure testing applications, controlled operation and compliance with the correct testing procedure are essential for repeatable results and operator safety.

Test Report Printing and USB Connectivity

One of the key features of the Seide OSM1000 is its test output and USB connectivity capability.

These features support the documentation of testing operations and can help quality control departments maintain test-related records.

Test documentation is particularly valuable for:

  • Manufacturing quality control

  • Hose assembly inspection records

  • Hydraulic cylinder service documentation

  • Production traceability processes

  • Internal quality management procedures

The available report format and data content should be confirmed according to the machine's software configuration.

Water and Hydraulic Oil Testing Capability

The Seide OSM1000 supports testing with two different test media:

  • Water

  • Hydraulic oil

This flexibility allows the machine to accommodate different testing requirements and component compatibility considerations.

The selection of test media should be based on the component materials, seal compatibility, cleanliness requirements, and manufacturer's recommendations.

The hydraulic circuit must also be properly prepared before testing.

Integrated Pre-Filling Pump

The Seide OSM1000 is equipped with a pre-filling pump to assist in filling the test circuit before pressure testing.

Proper pre-filling is an important part of test preparation. The circuit must be filled and prepared according to the applicable procedure, including appropriate air removal.

This preparation supports more controlled testing conditions.

Who Should Use the Seide OSM1000?

The Seide OSM1000 is suitable for a variety of businesses involved in hydraulic equipment manufacturing, assembly, testing, and maintenance.

Hydraulic Hose Manufacturers

For pressure testing and quality inspection of manufactured hose assemblies.

Hydraulic Hose Assembly Shops

For checking hose assemblies and crimped connections after assembly.

Hydraulic Cylinder Manufacturers

For pressure testing hydraulic cylinders during production quality control.

Hydraulic Cylinder Repair Facilities

For evaluating cylinder sealing performance after maintenance and overhaul.

Construction Equipment Service Centers

For testing hydraulic hoses and cylinders used in heavy equipment applications.

Industrial Manufacturing Facilities

For hydraulic component testing and maintenance quality control procedures.

How to Choose the Right Hydraulic Hose and Cylinder Test Machine

Selecting hydraulic testing equipment requires more than comparing maximum pressure ratings.

The testing machine must match the actual requirements of the components and the facility's quality control processes.

Important selection criteria include:

  • Required test pressure range

  • Types of hydraulic hoses and cylinders

  • Test fluid compatibility

  • Hydraulic connections and adapters

  • Pressure control and monitoring

  • Test report and data recording capabilities

  • Operator safety requirements

  • Available testing area

  • Daily testing volume

  • Maintenance and service requirements

Choosing the correct hydraulic test equipment helps improve the consistency and organization of testing operations.

Seide OSM1000 from Hidroman

Hidroman provides hydraulic equipment, manufacturing solutions, and application-oriented engineering support for industrial and mobile hydraulic applications.

The Seide OSM1000 Hydraulic Hose and Cylinder Test Machine is part of Hidroman's product portfolio for high-pressure hydraulic testing applications.

Hidroman's hydraulic equipment and engineering solution areas include:

  • Hydraulic hose manufacturing and assembly equipment

  • Hydraulic hose testing machines

  • Hydraulic cylinder testing and service equipment

  • Mobile hydraulic filtration and flushing machines

  • Hydraulic power units

  • Custom hydraulic cylinder manufacturing

  • Hydraulic testing and control systems

With its experience in hydraulic system engineering and equipment solutions, Hidroman supports industrial businesses in selecting equipment suited to their technical and operational requirements.

Contact Hidroman to request technical information and pricing for the Seide OSM1000 Hydraulic Hose and Cylinder Test Machine.

Frequently Asked Questions

What is the maximum test pressure of the Seide OSM1000?

The Seide OSM1000 has a test pressure range of 50 to 1,000 bar, equivalent to approximately 725 to 14,504 PSI.

Can the Seide OSM1000 test hydraulic hoses?

Yes. The machine is designed for hydraulic hose testing, including appropriate pressure and leak inspection procedures for hose assemblies.

Can the Seide OSM1000 test hydraulic cylinders?

Yes. The machine is also designed for hydraulic cylinder testing when suitable connections and testing procedures are used.

What test fluids can be used with the OSM1000?

The machine supports water and hydraulic oil as test media.

Does the Seide OSM1000 have PLC control?

Yes. The machine is equipped with a PLC control screen.

Can test reports be printed?

Yes. The OSM1000 has a test output printing feature. The available report format and data content depend on the machine's software configuration.

Does the machine support USB connectivity?

Yes. The Seide OSM1000 includes USB connectivity.

What is the purpose of the pre-filling pump?

The integrated pre-filling pump assists in filling the test circuit before the pressure testing procedure begins.

Is 1,000 bar suitable for every hydraulic hose?

No. The test pressure must be selected according to the hose's rated pressure, manufacturer's instructions, and applicable testing requirements. The machine's maximum pressure rating should not be confused with the required test pressure of an individual component.

Why is hydraulic hose pressure testing important?

Pressure testing helps evaluate hose assembly integrity, connection leak-tightness, and performance under specified test conditions.

Why should hydraulic cylinders be pressure tested?

Pressure testing helps identify leakage and evaluate the sealing performance of hydraulic cylinders after manufacturing, repair, or maintenance.
