Custom Hydraulic Valve Design and Engineering Solutions

Every machine has specific operating conditions, movement requirements and hydraulic control needs. When standard hydraulic valves do not fully meet an application's technical or mechanical requirements, a custom hydraulic valve solution can provide a more suitable approach.

Hidroman supports industrial machinery manufacturers, mobile equipment OEMs and special-purpose machine projects with application-specific hydraulic valve solutions. Each application is assessed according to its operating pressure, flow rate, control requirements, response characteristics, installation space and operating environment.

Our engineering approach focuses on more than selecting an individual component. The objective is to identify a reliable, maintainable and application-appropriate hydraulic control solution that integrates with the wider hydraulic circuit.

What Is Custom Hydraulic Valve Design?

Custom hydraulic valve design involves developing or configuring a valve solution to meet specific application requirements when standard products do not provide the required functionality, installation arrangement or operating characteristics.

Depending on the application, the solution may involve directional control, pressure regulation, flow control, load holding or the coordinated operation of multiple hydraulic functions.

Custom hydraulic valve engineering may be considered when:

  • Standard valves cannot meet the machine's technical requirements.

  • Multiple hydraulic movements must operate in a defined sequence.

  • Installation space is limited and a more compact arrangement is required.

  • An existing hydraulic circuit needs modification or optimisation.

  • An OEM requires a dedicated hydraulic control arrangement.

  • Specific pressure, flow rate or response requirements must be addressed.

Not every application requires a completely new valve. In some projects, the most appropriate solution may involve selecting existing valves and integrating them into a purpose-designed circuit or manifold.

Key Engineering Considerations for Hydraulic Valve Design

Selecting the right hydraulic valve requires an assessment of the complete operating environment. Nominal pressure ratings and port dimensions alone are not sufficient to establish whether a valve is suitable for an application.

Operating pressure and pressure rating

The continuous operating pressure, maximum permitted pressure and potential pressure fluctuations must be considered. Pressure limitation and other necessary safety functions should be evaluated as part of the hydraulic circuit design.

Flow capacity and pressure drop

Valve flow capacity and internal pressure losses affect system performance, heat generation and energy efficiency. The expected flow rate, duty cycle and operating conditions should therefore be considered during component selection.

Hydraulic control functions

Depending on the machine, the required functions may include directional control, pressure regulation, flow control, check valve operation, load holding or proportional control.

The selected valve configuration must match the intended circuit function and the overall system architecture.

Response characteristics and control accuracy

Applications involving frequent movement changes, variable loads or precise actuator control may require careful consideration of valve response and dynamic behaviour.

The valve, actuator, pump and control system should be assessed as an integrated arrangement rather than as independent components.

Mounting, connections and integration

Port configuration, mounting dimensions, available installation space, electrical connections and service access can all influence valve selection.

For OEM applications, compatibility with the machine's mechanical layout and hydraulic connections is particularly important.

Hydraulic fluid and operating environment

Fluid viscosity, operating temperature, contamination levels and environmental conditions may affect valve performance and service life.

Appropriate filtration and hydraulic fluid cleanliness are also important considerations for reliable system operation.

Types of Hydraulic Valve Solutions

Different valve technologies can be considered according to the required hydraulic function and operating conditions.

Directional control valves

Used to control the direction of hydraulic flow and manage the movement of cylinders and hydraulic motors.

Pressure control valves

Used to limit, reduce or regulate pressure within the hydraulic circuit, depending on the selected valve function.

Flow control valves

Used to regulate hydraulic flow and influence actuator speed under defined operating conditions.

Check valves and load-holding valves

Used to prevent reverse flow or help maintain control of a load when incorporated into a suitably designed hydraulic circuit.

Proportional hydraulic valves

Used to provide variable control of flow or pressure when supported by the appropriate hydraulic and electronic control architecture.

Cartridge valves

Suitable for integration into compact hydraulic manifolds and custom valve blocks where the application requires a space-efficient arrangement.

The final selection depends on circuit requirements, flow capacity, pressure rating, control characteristics and integration constraints.

The Custom Hydraulic Valve Design Process

Hidroman approaches hydraulic valve projects by evaluating the machine's actual operating requirements and the relationship between the valve and the wider hydraulic system.

1. Application assessment

The machine's functions, operating sequence, load characteristics and working conditions are reviewed.

2. Hydraulic circuit evaluation

Required pressure, flow rate, control functions and existing hydraulic components are assessed.

3. Valve technology and control selection

Suitable valve types and control methods are identified according to the application requirements.

4. Design and integration

Where necessary, the mounting arrangement, hydraulic manifold, valve block and connection layout are evaluated to support system integration.

5. Technical verification

Depending on the project scope, operating parameters, required functions and compatibility with the hydraulic system are reviewed.

6. Implementation and commissioning

Manufacturing, assembly, testing and commissioning activities may be planned according to the agreed project scope.

The exact engineering and implementation activities depend on the application, available technical documentation and project requirements.

Custom Hydraulic Valve Solutions for OEM Manufacturers

For original equipment manufacturers (OEMs), hydraulic control directly influences machine performance, operating behaviour and serviceability.

A suitable valve solution should be evaluated alongside the machine's mechanical design, hydraulic cylinders or motors, pump capacity and control architecture.

Hidroman supports OEM and special-purpose machinery projects with hydraulic component selection, system integration and related hydraulic engineering activities.

Depending on the project, valve solutions may be assessed together with:

  • Hydraulic power units

  • Hydraulic cylinders and motors

  • Hydraulic manifolds and valve blocks

  • Hydraulic hoses and rigid pipework

  • Hydraulic filtration equipment

  • Pressure, flow and control components

This integrated approach helps ensure that component selection is considered in the context of the complete hydraulic system.

Benefits of Application-Specific Hydraulic Valve Engineering

A properly engineered hydraulic valve solution can offer several potential advantages:

  • Better alignment with the machine's operating requirements.

  • More efficient use of available installation space.

  • Hydraulic control functions tailored to the application.

  • Opportunities to reduce pressure losses through appropriate circuit design.

  • Improved accessibility for maintenance and servicing.

  • Greater consistency in hydraulic control arrangements across OEM machine platforms.

Actual results depend on the circuit architecture, component selection, manufacturing quality and operating conditions. Performance improvements should be evaluated against the requirements of each individual project.

Information Required for a Custom Hydraulic Valve Project

Providing accurate technical information helps establish the requirements for an appropriate solution.

Useful information includes:

  • Machine type and application

  • Required operating pressure and flow rate

  • Hydraulic movements and control functions

  • Existing pump, cylinder and hydraulic motor specifications

  • Current hydraulic circuit diagram

  • Port dimensions and available mounting space

  • Electrical or electronic control requirements

  • Operating temperature and environmental conditions

  • Existing valve manufacturer, model and technical datasheet, where available

Photographs of the installation, hydraulic schematics and mechanical drawings can also support the initial engineering assessment.

Custom Hydraulic Valve Design by Hidroman

Hydraulic valve selection should not be treated as an isolated component decision. Pressure, flow, control functions, installation requirements and operating conditions must be considered together to identify a suitable solution.

Hidroman provides engineering-oriented support for custom hydraulic valve applications, hydraulic system design, valve block and manifold integration, and OEM hydraulic projects.

Looking for a hydraulic valve solution for your machine?

Share your application requirements, existing hydraulic circuit information and technical specifications with Hidroman to request an engineering assessment for your project.
