Argo Hytos Hidrolik Valf Çeşitleri

Argo Hytos Hidrolik Valf Çeşitleri

Hidrolik Yön Kontrol Valfleri
Valfler, bir hidrolik devredeki akışkanın akış yönü kontrolünü ve hem hareket yönünün kontrolünü hem de cihazlarının (kapanmasını) durdurmasını sağlar. Solenoidle çalışan valflere ek olarak valfler ayrıca mekanik olarak kol veya kam ile hidrolik veya pnömatik olarak da çalıştırılır. Pilot kumandalı yön kontrol valfleri, 600 l/dk'ya kadar yüksek bir akış hızı elde etmek için tasarlanmıştır. Poppet tipi vanalar, son derece düşük iç hacim kayıpları ile bilinirler.

Genel Teknik Bilgiler

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• Directional control valves
• 0.00
• 0.00
• HA 0060
•

4/2 and 4/3 Directional Control Valves, Manually Operated

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• RPR3-04
• 30 (8)
• 320 (4641)
• DN04 (D02)
• HA 4018
•

• RPR3-06
• 80 (21)
• 350 (5076)
• DN06 (D03)
• HA 4004
•

• RPR1-10
• 140 (37)
• 350 (5076)
• DN10 (D05)
• HA 4084
•

4/2 and 4/3 Hydraulic Operated Directional Control Valves

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• RPH2-06
• 80 (21)
• 350 (5076)
• DN06 (D03)
• HA 4005
•

• RPH3-06
• 80 (21)
• 350 (5076)
• DN06 (D03)
• HA 4006
•

4/2 and 4/3 Solenoid Operated Directional Control Valves

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• RPE2-04
• 20 (5)
• 320 (4641)
• DN04 (D02)
• HA 4012
•

• RPE3-04
• 30 (8)
• 320 (4641)
• DN04 (D02)
• HA 4014
•

• RPE3-06
• 80 (21)
• 350 (5076)
• DN06 (D03)
• HA 4010
•

• RPET3-06
• 60 (16)
• 350 (5076)
• DN06 (D03)
• HA 4086
•

• RPE4-10
• 140 (37)
• 350 (5076)
• DN10 (D05)
• HA 4039
•

4/2 and 4/3 Solenoid operated Directional Control Valve with Auxiliary Lever Override

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• RPER3-06
• 80 (21)
• 350 (5076)
• DN06 (D03)
• HA 4026
•

4/2 and 4/3 Solenoid Operated Directional Control Valves, Wire Box

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• RPEW4-06
• 80 (21)
• 350 (5076)
• DN06 (D03)
• HA 4035
•

• RPEW4-10
• 140 (37)
• 350 (5076)
• DN10 (D05)
• HA 4044
•

4/2 and 4/3 Solenoid Operated Directional Control Valves, Lightline

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• RPEL1-04
• 30 (8)
• 250 (3626)
• DN04 (D02)
• HA 4037
•

• RPEL2-06
• 60 (16)
• 320 (4641)
• DN06 (D03)
• HA 4036
•

• RPEL1-10
• 100 (26)
• 250 (3626)
• DN10 (D05)
• HA 4046
•

4/2 and 4/3 Solenoid Operated Directional Control Valves, Bankable

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• RPEK1-03
• 20 (5)
• 250 (3626)
• DN03
• HA 4027
•

4/2 and 4/3 Solenoid Operated Directional Control Valves with Spool Position Sensor

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• RPE3-04*S*
• 30 (8)
• 320 (4641)
• DN04 (D02)
• HA 4014
•

• RPE3-06*S*
• 80 (21)
• 350 (5076)
• DN06 (D03)
• HA 4010
•

• RPE3-062x/xS3
• 80 (21)
• 350 (5076)
• DN06 (D03)
• HA 4087
•

• RPE4-10*S*
• 140 (37)
• 350 (5076)
• DN10 (D05)
• HA 4039
•

4/2 and 4/3 Directional Control Valves, Internally and Externally Pilot Operated

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• RNEH1-10
• 150 (40)
• 320 (4641)
• DN10 (D05)
• HA 4075
•

• RNEH5-16
• 300 (79)
• 350 (5076)
• DN16 (D07)
• HA 4023
•

• RNEH4-25
• 600 (159)
• 320 (4641)
• DN25 (D08)
• HA 4024
•

2/2 Directional Valves, Solenoid Operated, Spool Type, Screw-In Style

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• SD2E-A2
• 30 (8)
• 350 (5076)
• C-8-2 / 3/4-16 UNF
• HA 4040
•

• SD2E-B2
• 60 (16)
• 350 (5076)
• C-10-2 / 7/8-14 UNF
• HA 4060
•

3/2 Directional Valves, Solenoid Operated, Spool Type, Screw-In and Slip-In Style

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• PD2E1
• 30 (8)
• 80 (1160)
• slip-in
• HA 4050
•

• SD2E-A3
• 30 (8)
• 350 (5076)
• C-8-3 / 3/4-16 UNF
• HA 4041
•

• SD2E-B3
• 60 (16)
• 350 (5076)
• C-10-3 / 7/8-14 UNF
• HA 4061
•

4/2 Directional Valves, Solenoid Operated, Spool Type, Screw-In Style

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• SD2E-A4
• 30 (8)
• 350 (5076)
• C-8-4 / 3/4-16 UNF
• HA 4042
•

• SD2E-B4
• 60 (16)
• 350 (5076)
• C-10-4 / 7/8-14 UNF
• HA 4062
•

2/2 Directional Valves, Solenoid Operated, Poppet Type, Screw-In Style

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• ROE3-062S2
• 63 (17)
• 250 (3626)
• M22x1,5
• HA 4022
•

• SD3E-A2
• 30 (8)
• 420 (6092)
• C-8-2 / 3/4-16 UNF
• HA 4043
•

• SD3E-B2
• 75 (20)
• 420 (6092)
• C-10-2 / 7/8-14 UNF
• HA 4063
•

• SD3E-C2
• 150 (40)
• 350 (5076)
• C-12-2 / 1-1/16-12 UN
• HA 4078
•

2/2 Directional Valves, Solenoid Operated, Poppet Type, Modular Design

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• ROE3-062S2M
• 25 (7)
• 250 (3626)
• DN04 (D02), DN06 (D03)
• HA 4072
•

2/2 Directional Valves, Solenoid Operated, Poppet Type, Blocking, Screw-In Style

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• ROE3-042S5(S6)
• 25 (7)
• 250 (3626)
• M22x1,5
• HA 4055
•

• SD1E-A2
• 30 (8)
• 350 (5076)
• C-8-2 / 3/4-16 UNF
• HA 4070
•

2/2 Directional Valves, Solenoid Operated, Poppet Type, Blocking, Modular Design

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• ROE3-042S5(S6)M
• 25 (7)
• 250 (3626)
• DN04 (D02), DN06 (D03)
• HA 4073
•

3/2 Directional Valves, Solenoid Operated, Poppet Type, Blocking, Screw-In Style

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• SD1E-A3
• 30 (8)
• 350 (5076)
• C-8-3 / 3/4-16 UNF
• HA 4071
•

2/2 Directional Valves, Manually Operated, Screw-In Style

• Type
• Q max. l/min (GPM)
• P max. bar (PSI)
• Connection
• Data sheet
• Download

• SD1M-A2
• 20 (5)
• 250 (3626)
• C-8-2 / 3/4-16 UNF
• HA 4051
•

• ROR3-062
• 35 (9)
